The second argument to postMessage controls which origin is allowed to receive the data, the browser runs that value through its URL parser before comparing anything and the parser rewrites some hosts. A host that’s a plain number gets read as an IPv4 address and written back in dotted form, so 2130706433 becomes 127.0.0.1. Hex, octal, and short forms like 127.1 behave the same.

Common origin restrictions can be hacked with this, a page might take a user-controlled origin, check it with a regex like https?://[^.]+[.]target[.]com to allow only subdomains of target.com then hand it to postMessage. The regex runs on the raw string, so http://2130706433/.target.com gets through. The [^.]+ was supposed to match one subdomain label, but a slash isn’t a dot, so it eats 2130706433/ and lets .target.com cover the rest.

That hands postMessage the call:

window.postMessage('message_here', 'http://2130706433/.target.com')

That input isn’t a subdomain of anything, though. Once parsed, the host is 2130706433, which normalizes to 127.0.0.1, and /.target.com is just a path that origin checks ignore. The data goes to http://127.0.0.1, which the attacker controls.

@siunam checked the spec and it’s all “intended behaviour”. postMessage sends targetOrigin through the URL parser, host parsing converts the number to a 32-bit integer, and the serializer prints it back in dotted form.

Mathias brought this up in the #researchers exclusive chat and we decided that this is a cool find to post! =)

- CTBB
